Loading port on JM 930 , How much!

Karsten Andreasen · Jan 13, 2015

Hi there

Does anyone have Pictures on how much you opened the loading port on your JM 930 PRO?

I do L2 loading and IÂ´m not sure if i can open the port to much or the more the better?

Thanks

Matt1911 · Jan 13, 2015

You don't want to go so much that you alter the function of the shell catch.
Take it slow and work by hand, not a Dremel.

Tuflehundon · Jan 13, 2015

Here are a couple of pics of mine. Non loading port side I went all the way down to the angled area. Loading port side I went down until I was about to hit the pin for the carrier latch. Front I rounded off so it no longer says Mossberg 930. Last 2 pics are older, I went down a little farther since those pics. Top pic is final product. I can get more pics tomorrow. Gun is in the safe and the wife is asleep.

Karsten Andreasen · Jan 14, 2015

thanks for the Pictures.. .-)

Tuflehundon · Jan 14, 2015

No problem. As Matt said, take your time and go slow. I actually did mine in 4 different sessions. Took some off, tried it out, and then took some more off. Happened over about 5 or 6 months before I got it were a realy liked it. Most of the guys I shoot with didn't go as far as me, but I have huge hands so taking off more helps me. I used a file to do all of the trimming and only used a dremel with a sanding disk to smooth things out.

c_hatch · Jan 19, 2015

Anyone know of a place in texas that I could take mine? I dont really want to send it off to crums, I did mine but I just want to have someone clean it up a bit.

Trunk Monkey · Feb 20, 2015

Here is my first loading port attempt. I just sent my carrier off to C-rums to be welded so I won't know if I took off enough for a couple of weeks.

Sent from my iPhone using Tapatalk

Robaire Pullicar · Feb 20, 2015

I find the hand guard a bigger issue than the port but I'm loading quads

Matt1911 · Feb 20, 2015

Purty

Trunk Monkey · Feb 20, 2015

Thanks, I have started beveling the hand guard but will probably take off some more before I finish it. I also am having to send the barrel back to mossberg because the screw in chokes were threaded offset to the bore. You really noticed it when you put the Briley extended choke in.

Sent from my iPhone using Tapatalk

Feegee · Feb 20, 2015

Feegee · Feb 20, 2015

cajunautoxer · Feb 21, 2015

c_hatch said:
Anyone know of a place in texas that I could take mine? I dont really want to send it off to crums, I did mine but I just want to have someone clean it up a bit.

What part of TX are you? Dissident Arms (Houston) did mine and at the same time I had them replace my firing pin at the same time since they are soft and can mushroom after 1k rounds. Mine did around 1300 shells. My SPX had 3k and still worked when I bought my Pro
